BX30Plus / BX30DPlus Weighing Indicator
Baykon BX30Plus & BX30DPlus are high accurate, Multifunctional Weighing Terminals which are used in wet, hygienic and harsh industrial areas.
This Weighing Indicator can be programmable for weighing, labelling, checkweighing, classifying, filling, peak hold and dynamic weighing applications. Three user programmable keys can be set for user applications to provide practical and error free operation. The instrument has 4 pcs memories; ID1, ID2, preset tare, item limit values; each have 500 records capacity.
BX30Plus & BX30DPlus have important features for process weighing; strong calibration alternatives including electronic calibration (eCAL) and various integration interfaces with PC or PLC via RS232C, RS485, RS422, USB, Ethernet TCP/IP as a standard. Fieldbuses such as Profibus, Profinet, CANopen, EtherCAT, CC-Link, Powerlink, Modbus RTU, Modbus TCP, EtherNet/IP, analogue output, digital I/O are optional.
Highlights
Measurement Type
Weight Measurement
Applications
Basic Weighing, Simple Filling, Portioning, Manual Packaging, Classification, Manual Weight Control, Labelling, Totalization, Dynamic Weighing, Tank Weighing, Truck Scale, Basic Peak-Hold, Capture of Weight (HOLD), Advanced Peak-Hold
Protection Class
IP67
Type of Device
Panel
Serial Communication
Analogue Output, RS232, RS485, RS422, USB, Modbus RTU
Industrial Communication
Modbus TCP, Ethernet TCP/IP, Profinet, Profinet S2, Profibus, EtherCAT, EtherNet/IP, CANopen, Powerlink, CC-Link
Web/PC Access
Configuration by App, Data Collection
IoT
Yes
Digital Input & Output
Input, Output
Energy Supply
12V DC, 24V DC
Certificate
OIML
Trade Approval
Yes
Other Features
Unit Conversion, Alibi Memory, Data Logging, eCal, sCal, Multi-point adjustment
Functional Features
Main Features
• IP67 protected front panel for wet and harsh areas
• Color changing display, SmartAPP & 16 digit alphanumeric info line
• User programmable 3 keys
• On board Ethernet TCP/IP
High Technology & Performance
• Up to 300 000 display resolution
• Up to 1600 conversions per second
• Application based SmartBars
• Changing color for prompting
• High capacity tank scales supported by eCAL - electronic calibration & span correction of non-empty tanks
Typical Applications
• Weighing and data collection
• Customized labelling with barcode
• Classification, checkweighing, filling and peak hold
• Livestock and dynamic weighing with strong filters and algorithm
4 Memories Each With 500 Items
• 2 pcs ID1 & ID2 identification data
• Preset tare to enter specific tare
• Limit values memory for weighing
• Item limits for check weighing and for classifying of packages
• Automatic memory linkage to ID
Integration & Connectivity
• Profibus, Profinet, CANopen, Ethernet TCP/IP, EtherNet/IP, EtherCAT, CC-Link, Powerlink, Modbus RTU, Modbus TCP, analogue output and digital I/Os
• Galvanically isolated, RS232C and RS485, RS422 serial ports
• Micro USB port
• Ethernet TCP/IP
Technical Specifications
BX30Plus / BX30DPlus Weighing Indicator
Technical Specifications
