BX30 / BX30D Weighing Indicator

Baykon BX30 & BX30D are Low Cost Panel Type Weighing Indicators; offer high accuracy, and performance with strong connectivity options for all weighing applications. With its IP67 protected stainless steel front panel, it provides reliable and safe operation in wet, hygienic and harsh industrial areas.



BX30 & BX30D have strong calibration alternatives including eCAL electronic calibration which is extremely important tool for heavy capacity tank scales and calibration of tanks without emptying.



For connectivity, BX30 & BX30D have RS232C, RS485, RS422, USB and Ethernet TCP/IP as a standard; and Analogue output, EtherNet/IP, Profibus, Profinet, Modbus RTU, Modbus TCP, CANopen, EtherCAT, CC-Link, Powerlink and Digital I/O with 4 opto isolated inputs and 5 relay outputs, are supplied as variants of interfaces.

Compare

Highlights

Measurement Type

Weight Measurement

Applications

Basic Weighing, Labelling, Dynamic Weighing, Tank Weighing, Truck Scale, Basic Peak-Hold, Capture of Weight (HOLD)

Protection Class

IP67

Type of Device

Panel

Serial Communication

Analogue Output, RS232, RS485, RS422, USB, Modbus RTU

Industrial Communication

Modbus TCP, Ethernet TCP/IP, Profinet, Profinet S2, Profibus, EtherCAT, EtherNet/IP, CANopen, Powerlink, CC-Link

Web/PC Access

Configuration by App, Data Collection

IoT

Yes

Digital Input & Output

Input, Output

Energy Supply

12V DC, 24V DC

Certificate

OIML

Trade Approval

Yes

Other Features

Unit Conversion, Alibi Memory, Data Logging, eCal, sCal, Multi-point adjustment

certificates
certificates
certificates
certificates
certificates

Functional Features

Main Features

functional

• Stainless steel front panel, IP67 protected for wet, hygienic and harsh areas
• Color selectable LCD display with alphanumeric info line
• Bar graph to follow gross weight capacity
• Key based locking against interfering

High Technology & Performance

functional

• Up to 300 000 display resolution
• Up to 1600 conversions per second
• Smart and adaptive filter
• High capacity tank scales supported by eCAL - electronic calibration
• Span adjustment of loaded tanks without emptying

Typical Applications

functional

• Process weighing applications; tank, silo, hopper and conveyor weighing
• Livestock and dynamic weighing with strong dynamic weighing algorithm
• Warning with display color at malfunction

Integration & Connectivity

functional

• Galvanically isolated, RS232C and RS485, RS422
• Ethernet TCP/IP
• Micro USB port
• Profibus, Profinet, CANopen, EtherNet/IP, EtherCAT, CC-Link, Powerlink, Modbus RTU / TCP and analogue outputs with digital I/O

Technical Specifications

BX30 / BX30D Weighing Indicator

Technical Specifications

Documents

Name

Version

Description

Category

Data Type

BX30_BX30D Weighing Indicator Catalogue

Product Catalogs

EU Type Examination_BX23-BX24-BX25-BX26-BX30

Certificates

OIML Certificate Of Conf (BX30)

Certificates
