BR200S Ring Type Load Cell
Type BR200S is OIML R60 C3 approved, low profile, high performance stainless steel ring torsion type load cell with complete IP68 hermetic sealing.
It has a wide capacity range from 5 t to 50 t perfectly fits for use in harsh industrial environments in food, chemical and allied process industries.
For explosive atmospheres, order the ATEX approved version.
Highlights
Connection
Analogue
Type
Ring Type
Applications
Truck Scales, Tank & Silo Weighing, High Capacity Applications, Special Weighing, Industrial Processes, Test Machines
Certificate
OIML, ATEX
Material
Stainless Steel
Maximum Capacity
2.5 t, 5 t, 10 t, 15 t, 20 t, 30 t, 50 t
Protection Class
IP68
Functional Features
Truck Scales
Wagon Scales
Silo Weighing Systems
Special Weighing Applications
