BR110/BR110S Ring Type Load Cell
BR110 and BR110S are compression-type load cells that are hermetically welded, IP68-protected and are designed for general weighing applications. They are available in alloy steel and stainless-steel versions.
BR110S stainless steel version is EU OIML C3 approved in 10-47 t capacities. It can be used in high-capacity floor scales, tank scales, ship weighing and similar weighing applications.
The BR110HT version is used extensively in weighing applications in high-temperature environments up to 150°C, especially in the steel industry.
For explosive atmospheres, order the ATEX approved version.
Highlights
Connection
Analogue
Type
Ring Type
High Temperature
Yes
Applications
Explosive Environment, Truck Scales, Tank & Silo Weighing, High Capacity Applications, Special Weighing, Industrial Processes, Test Machines
Certificate
OIML, ATEX
Material
Stainless Steel, Nickel Plated Steel
Maximum Capacity
1 t, 2.2 t, 4.7 t, 10 t, 15 t, 22 t, 33 t, 47 t, > 50 t
Protection Class
IP68
Functional Features
Truck Scales
Wagon Scales
Silo Weighing Systems
Special Weighing Applications
Technical Specifications
BR110/BR110S Ring Type Load Cell
Technical Specifications
Dimensions
