BX23 Ex2/22 Weighing Indicator

Baykon BX23 Ex2/22 is a Weighing Terminal offers high accuracy and performance with strong connectivity options for weighing applications in hazardous areas. With its IP67 protected stainless steel housing, it provides reliable and safe operation in wet, hygienic and harsh industrial areas. BX23 Ex2/22 is certified for ATEX and IECEx and can be used in the zones 2/22 hazardous areas having explosive gases and dust.



BX23 Ex2/22 has strong calibration alternatives including eCal-electronic calibration, which is an extremely important tool for heavy cpacity tank scales and for the calibration of tanks without emptying.



For connectivity, BX23 Ex2/22 is certified for the following interfaces: 2 x RS232C, 1 x RS485, and Ethernet TCP/IP, Modbus RTU, Modbus TCP as standard; and Analogue output, EtherNet/IP, Profibus, Profinet, EtherCAT, CC-Link, Powerlink and Digital I/O with 4 opto isolated inputs and Opto-isolated 5 transistor outputs as option.



Add to Comparison List

Highlights

Measurement Type

Weight Measurement

Applications

Basic Weighing, Labelling, Dynamic Weighing, Tank Weighing, Truck Scale

Protection Class

IP67

Type of Device

Desk, Wall

Serial Communication

Analogue Output, RS232, RS485, USB, Modbus RTU

Industrial Communication

Modbus TCP, Ethernet TCP/IP, Profinet, Profinet S2, Profibus, EtherCAT, EtherNet/IP, Powerlink, CC-Link

Web/PC Access

Configuration by App, Data Collection

Digital Input & Output

Input, Output

Energy Supply

12V DC, 24V DC, 110-230V AC, Battery

Certificate

OIML, ATEX

Trade Approval

Yes

Other Features

Unit Conversion, Alibi Memory, Data Logging, eCal, sCal, Multi-point adjustment

certificates
certificates
certificates
certificates
certificates
certificates

Functional Features

Main Features

functional

• Multi-language operator prompts
• Stainless steel, IP67 protected for wet, hygienic and harsh areas
• Color selectable LCD display with alphanumeric info line.
• Bar graph to follow gross weight capacity.
• Key locking against interfering.

High Technology & Performance

functional

• Up to 999 999 display resolution.
• Up to 1600 conversions per second.
• Smart and adaptive filter.
• High capacity tank scales supported by eCAL - electronic calibration.
• Span adjustment of loaded tanks without emptying.

Typical Applications

functional

• Weighing in the hazardous areas. ATEX and IECEx approvals for;
• Gases: Hydrogen, propan, etylene, acetylene, carbon disulfide etc.
• Dust: Carbon, magnesium, flour, grain, rayon, cotton lint, flax etc.
•  Scales and Process weighing

Integration & Connectivity

functional

• Zone 2/22 Certified interfaces;
• 2 x RS232C, 1 x RS485.
• Ethernet TCP/IP,
• Profibus, Profinet, EtherNet/IP, EtherCAT, CC-Link, Powerlink,
• Analogue output and Digital I/O.

Technical Specifications

BX23 Ex2/22 Weighing Indicator

Technical Specifications

Dimensions

Documents

Name

Version

Description

File Size

Update Date

Category

Data Type

BX23 Ex Weighing Indicator Catalogue

339.33 KB

22/02/2024 09:46:07

Product Catalogs

ATEX Type Examination Certificate (BX2x)

178.84 KB

07/05/2024 16:34:14

Certificates

IECEx Certificate of Conformity (BX2x)

167.75 KB

25/01/2024 14:43:46

Certificates
