BX11 Weighing Indicator
Baykon BX11, is a smart indicator for industrial weighing process applications offering powerful PLC integration facilities; serial ports as RS-232C, RS-485, 4 digital inputs and 5 digital outputs, Ethernet, Analog Output and fieldbus connections such as EtherNet/IP, Modbus, Profibus, Profinet, CANopen, EtherCAT and CC-Link.
Powerful calibration options including electronic calibration without test weights supports easy and fast start-up and service. BX11 is featuring adaptive filtering for fast settling, high display resolution and 1600 conversion per secondspeed.
It's small size aluminium body provides perfect panel installation with its big display and with its small space need on control panels. The instrument has stainless steel front panel for usage in harsh environments.
Highlights
Measurement Type
Weight Measurement, High Resolution A/D Value
Applications
Basic Weighing, Tank Weighing, Basic Peak-Hold, Capture of Weight (HOLD)
Protection Class
IP67
Type of Device
Panel
Serial Communication
Analogue Output, RS232, RS485, Modbus RTU
Industrial Communication
Modbus TCP, Ethernet TCP/IP, Profinet, Profinet S2, Profibus, EtherCAT, EtherNet/IP, CANopen, Powerlink, CC-Link
Web/PC Access
Configuration by App
Digital Input & Output
Input, Output
Energy Supply
12V DC, 24V DC
Certificate
OIML
Trade Approval
Yes
Other Features
eCal, sCal, Multi-point adjustment
Functional Features
Features
• Up to 1600 measurement per second
• 16.000.000 internal counter
• Ergonomic design with small size
• 13,5 mm LED display
• eCal Electronic calibration
• Programmable via PC
• RS-232C & RS-485 serial interface
• 4 digital input 5 Relay contact output
System Integration
• 4-20 mA, 0-10 V analogue output
• RS-232C / RS 485
• Modbus RTU, Modbus TCP
• Ethernet TCP/IP, EtherNet/IP
• EtherCAT
• Profibus, Profinet
• CANopen
• CC-Link
Technical Specifications
BX11 Weighing Indicator
Technical Specifications
Dimensions
