BX13 Filling Controller

Baykon BX13 Filling Controller, is a Proffessional Filling Controller designed for any type of Filling Processes of liquid, Bulk and Granule Material with all types of packages.



With its 16.000.000 internal resolution, high speed with up to 1600 measurements per second, selectable standard digital and statistical filters, BX13 provides fast and accurate filling results in even harsh environments with vibrations. It has 4 standard filling modes for open container filling and above level bung hole filling; 1 mode for filling of materials which has high viscosity and 3 modes for packing machines. This controller has 4 opto-isolated digital inputs and 5 relay contact outputs, 2 none - isolated output. They are used for filling and disacharge processes.



Powerful calibration options including electronic calibration without test weights supports easy and fast start-up and service. BX13 has powerful PLC integration facilities; serial ports as RS-232C, RS-485 and fieldbus connections such as Ethernet TCP/IP, Modbus RTU/TCP, Profibus, Profinet, CANopen, EtherNet/IP, EtherCAT, CC-Link and Powerlink.



It's small size aluminium body provides perfect panel installation with its big display and with its small space need on control panels.



Add to Comparison List

Highlights

Measurement Type

Weight Measurement

Applications

Simple Filling, Totalization, Tank Weighing, Silo Weighing, Liquid Filling, Packaging, Bagging, Tank Filling/Discharging, Process Control

Protection Class

IP67

Type of Device

Panel

Serial Communication

RS232, RS485, Modbus RTU

Industrial Communication

Modbus TCP, Ethernet TCP/IP, Profinet, Profinet S2, Profibus, EtherCAT, EtherNet/IP, CANopen, Powerlink, CC-Link

Web/PC Access

Configuration by App

Digital Input & Output

Input, Output

Energy Supply

12V DC, 24V DC

Certificate

OIML, MID

Trade Approval

Yes

Other Features

eCal, sCal, Multi-point adjustment

certificates
certificates
certificates
certificates

Functional Features

Advanced Technology

functional

• 16.000.000 internal resolution
• Up to 1600 measurement values per second
• Display resolution up to 999.999 increment
• Easy control 4 Inputs and 7 Outputs
• Ergonomic design with small size

Filling Modes

functional

• Liquid filling for open containers, filling under bung hole or at bottom filling
• “Weigh in and emptying” mode for automatic packing machines, bag fillers
• Filling and discharging for tanks or silos

External Programming

functional

• Calibration is performed with or without test weights (eCal)
• Easy programming and calibration via RS-232C port by BAYKON “IndFace1x” software
• Calibration via PLC interfaces

System Integration

functional

• RS-232C / RS 485
• Modbus RTU, Modbus TCP
• Ethernet TCP/IP, EtherNet/IP
• EtherCAT
• Profibus, Profinet
• CANopen
• CC-Link
• Powerlink

Technical Specifications

BX13 Filling Controller

Technical Specifications

Dimensions

Documents

Name

Version

Description

File Size

Update Date

Category

Data Type

BX13 Filling Controller Catalogue

249.43 KB

22/02/2024 10:41:55

Product Catalogs

OIML Certificate Of Conf (BX1x)

129.04 KB

25/01/2024 11:41:44

Certificates

OIML Certificate Of Conf (BX13)

231.99 KB

25/01/2024 15:42:24

Certificates
